Code:  USRG00800710

Material: aluminum

Working load: 240 kg  (people) / 440 kg (load)

Rectangular base: 300 x 250 mm

Weight: 6 Kg (approx.)

• The Agile rescuer with two speeds is a high-performance portable version for use in confined spaces using Kernmantle ropes (cover and core).

• It is easily attachable to the tripod quickly and efficiently, using a "U" profile equipped with two fixing holes and the insertion of two strong stainless steel and aluminum pins with self-locking system.

• The base plate of the rescuer has two holes to be used as anchoring points for the ropes with a backup system using a blocking knot (prussik).

• Power ratios (depending on the direction of rotation): A) 1: 13.50 turning counterclockwise B) 1: 35.90 turning clockwise

• Transmission ratios: A) 1: 2.13 turning counterclockwise B) 1: 5.65 turning clockwise

• Types of attachment on tripods:

• There are three versions depending on the model of tripod to be used:




  • Version 00 (Ultra Safe): "U" profile for attachment on tripods with 43mm diameter aluminum tubes and Ø10mm holes with a distance of 75mm between them.

  • Version 01 (Sked or similar): "U" profile for attachment on tripods with 52mm diameter aluminum tubes and Ø10mm holes with a distance of 127mm between them.

  • Version 02 (Task or similar): "U" profile for attachment on tripods with 48mm diameter aluminum tubes and Ø13mm holes with a distance of 129mm between them.
