CODES
USR009123 (Red with black)
USR009124 (White with red)
USR009125 (Blue with white)
TECHNICAL DESCRIPTION
Semi-static Rope VIPER – Type A
Rope Composition: 60% Polyamide (Core) and 40% High Tenacity Polyester (Sheath);
Sheath & Core: “KERNMANTLE” type with low elasticity;
Diameter: 11 mm
Breaking Load: 31 kN
Yield m/Kg: 10 m/Kg
SPECIFICATION
• Rope manufactured following the standards of NBR-15986;
• Semi-static rope made in the KERMMANTLE sheath and core system;
• In the nominal resistance or breaking load informed,
consider a tolerance of up to -10% according to NBR ISO 2307;
• Only ropes above 11 mm can be used in life line applications
(see the technical characteristics table below).
