Code: USP400850100

Features
Approx. weight: 254 g
Rope diameter: ø ≤ 12 mm
Internal pulley diameter: 27 mm
Internal pulley mechanism: self-lubricating bearings
Use: for NORMAL or INTENSE use
High-speed use: DO NOT use Lift and Roll pulleys at high speeds
Friction coefficient in bearings – f (dry): 0.02 – 0.25
Maximum sliding speed in bearings – U (dry): 2.5 m/s
Maximum static load in bearings – P: 250 N/mm2

Usage
Work at height, rescue, hoisting, and force multiplication systems.
Nylon 6 Sheave
Nylon 6.0 is a thermoplastic obtained from polyamide 6, whose excellent mechanical,
electrical, and thermal properties allow for a wide range of applications in various sectors
of the mechanical, electrical, and chemical industries. Its substitution for metals as
structural and/or construction materials is advantageous as it considers lightness, low friction
coefficient, electrical insulation, and good resistance to fatigue and chemical agents.
The Nylon 6 sheave
• Provides less wear on the rope;
• Does not cause corrosion;
• Makes the pulley lighter;
• Provides greater resistance to friction;
• Is completely resistant to salinity;
• Has UV protection (5-year warranty).
General Recommendations
• Avoid dropping the pulley;
• Do not overload the pulley (NEVER exceed the recommended working load!);
• NEVER use Roll D pulleys on steel cables;
• NEVER use Roll D pulleys on zip lines.
