Code: USP40094000

Features:
Approx. weight: 1330 g
Steel cable diameter: ø ≤ 55 mm
Internal diameter of pulley: 54 mm
Internal pulley mechanism: carbon steel bearing
Use: for NORMAL use
Maximum sliding speed
on bearings – U (dry): 2.5 m/sec.
Working load: 5 kN
Breaking load: 36 kN
Measured height: 470 mm (without swivel*).
Nylon 6 Sheave
Nylon 6.0 is a thermoplastic derived from polyamide 6, whose excellent mechanical, electrical, and thermal properties allow for the most varied applications across various branches of the mechanical, electrical, and chemical industries.
Its substitution for metals as structural and/or construction materials is advantageous because Nylon 6 offers lightness, low friction coefficient, electrical insulation, complete resistance to salinity, UV protection, and good resistance to fatigue and chemical agents.
